MK1001433 CV Axle Drive Shaft Set (Front & Rear) Product Info:

• Rear Left Compressed Length 27 3/8, Inboard Splines 27T/29T, Inboard Spline Diameter 2 11/16, Outboard Splines 26T, Outboard Spline Diameter 3, Shaft Diameter 13/16, Thread Measurement M18X1.5
• Rear Right Compressed Length 26, Inboard Splines 27T, Inboard Spline Diameter 2 3/4, Outboard Splines 26T, Outboard Spline Diameter 3, Shaft Diameter 13/16, Thread Measurement M18X1.5

Included in This Kit:

(QTY 2) NICHE 519-KCA2246X Front Drive Shaft CV Axle Assembly

Substitute For OEM Part Numbers(s): 1332467

(QTY 1) NICHE 519-KCA2272X Rear Left Drive Shaft CV Axle Assembly

Substitute For OEM Part Numbers(s): 2204857, 2203741, 1332876, 1332721, 1332647, 1332575, 1332502

(QTY 1) NICHE 519-KCA2273X Rear Right Drive Shaft CV Axle Assembly

Substitute For OEM Part Numbers(s): 2204858, 2203742, 1332877, 1332722, 1332648, 1332576, 1332503

Compatible with the Following Vehicles:

Polaris Ranger XP 700: 2008
Polaris Ranger Crew 700: 2008-2009
Polaris Ranger 800 MVRS: 2008
Polaris Ranger 700 MVRS: 2008-2010
Polaris Ranger 700 6X6: 2008-2009
Polaris Ranger 500 EFI: 2008
