MK1001435 Front & Rear CV Axle Set Product Info:

• Front Compressed Length 26 1/4, Inboard Splines 22T, Inboard Spline Diameter 2 11/16, Outboard Splines 26T, Outboard Spline Diameter 2 3/4, Shaft Diameter 7/8, Thread Measurement M18X1.5
• Rear Compressed Length 26 7/16, Inboard Splines 28T, Inboard Spline Diameter 2 3/4, Outboard Splines 26T, Outboard Spline Diameter 3, Shaft Diameter 13/16, Thread Measurement M18X1.5

Included in This Kit:

(QTY 2) NICHE 519-KCA2253X Front Half Drive Shaft CV Axle Assembly

Substitute For OEM Part Numbers(s): 1332856, 1332606

(QTY 2) NICHE 519-KCA2262X Rear Drive Shaft CV Axle Assembly

Substitute For OEM Part Numbers(s): 1590476, 1333233, 1333008, 1332878, 1332814

Compatible with the Following Vehicles:

Polaris Ranger XP 800 Limited: 2010-2011
Polaris Ranger XP 800 EPS Limited: 2012
Polaris Ranger XP 800 EPS: 2012
Polaris Ranger XP 800: 2010-2012
Polaris Ranger HD 800 EPS: 2012
Polaris Ranger HD 800: 2010-2012
Polaris Ranger Crew 800 Military: 2010-2011
Polaris Ranger Crew 800 EPS Limited: 2011-2013
Polaris Ranger Crew 800 EPS: 2010-2014
Polaris Ranger Crew 800: 2010-2014
Polaris Ranger 800 Limited: 2013-2014
Polaris Ranger 800 EPS Limited: 2013-2014
Polaris Ranger 800 EPS: 2013-2014
Polaris Ranger 800: 2013-2014
Polaris Ranger 500 EFI: 2010
