MK1008441 Wheel Bearing Seal Kit Product Info:

• Bearing 1 Diameter Inner (ID)15mm; Outer (OD) 35mm; Height 11mm; Bearing 2 Inner (ID)28mm; Outer (OD) 58mm; Height 16mm
• Bearing 3 Diameter Inner (ID)40mm; Outer (OD) 68mm; Height 15mm; Bearing 4 Inner (ID)20mm; Outer (OD) 37mm; Height 9mm
• Seal 1 Diameter Inner (ID) 21mm; Outer (OD) 35mm; Height 7mm; Seal 2 Diameter Inner (ID) 35mm; Outer (OD) 52mm; Height 7mm
• Seal 3 Diameter Inner 49mm; Outer 62mm; Height 6mm; Seal 4 Inner 46mm; Outer 68mm; Height 8mm; Seal 5 Inner 42mm; Outer 68mm; Height 8mm

Included in This Kit:

(QTY 2) NICHE 519-CBB2227R Single Row, Deep Groove, Ball Bearing

Substitute For OEM Part Numbers(s): M800578, KKK60-1B620-2UU, 96150-62020-10, 96150-62020, 96140-62020-10, 96100-62020-00, 96100-62020, 92045-Y025, 92045-S036, 92045-0734, 92045-0112, 91140-62020-10, 91074-GBF-831, 91072-GC4-601, 91052-HC4-003, 91052-HC4-000, 91051-KEB-G01, 91014-KPS-761, 91014-KPS-732, 91014-KPS-731, 91006-GFC-901, 91002-HB6-000, 625062028, 601B6202UU, 601B6202U, 601B202UU, 3514650, 3514528, 3514464, 339932X1, 3304-202, 09262-15024, 09262-15021, 08284-62027, 08143-62027, 08123-62027, 08113-62027, 0625062028, 0625062027

(QTY 2) NICHE 519-CBB2235R Single Row, Deep Groove, Ball Bearing

Substitute For OEM Part Numbers(s): 93306-278Y0-00, 93306-20531-00, 91057-HA8-004, 91057-HA8-000, 91057-HA0-681

(QTY 2) NICHE 519-CBB2253R Single Row, Deep Groove, Ball Bearing

Substitute For OEM Part Numbers(s): 93306-00804-00, 93306-00803-00, 92045-S049, 601A6008UU, 339780X1, 3304-688, 08123-60087, 0402-393

(QTY 2) NICHE 519-CBB2258R Single Row, Deep Groove, Ball Bearing

Substitute For OEM Part Numbers(s): K9204-51284, 93306-90409-00, 93306-90403-00, 92045-S061, 92045-1284, 92045-1136, 91062-MAC-681, 91051-HB3-003, 08130-69047

(QTY 2) NICHE 519-CSE2225A Seal Type TC 21x35x7

Substitute For OEM Part Numbers(s): K9204-91469, 90752-GB4-682, 90752-GB4-681, 90752-360-006, 90752-035-003, 90752-035-000

(QTY 2) NICHE 519-CSE2244A Seal Type TC 35x52x7

Substitute For OEM Part Numbers(s): 93105-35025-00, 93102-35318-00, 93101-35097-00

(QTY 2) NICHE 519-CSE2321A Seal Type TC 49x62x6

Substitute For OEM Part Numbers(s): 93105-49023, 93102-48370-00

(QTY 2) NICHE 519-CSE2345A Seal Type TC 46x68x8

Substitute For OEM Part Numbers(s): 93102-46274-00

Compatible with the Following Vehicles:

Yamaha Timberwolf 250 4X4: 1994
Yamaha Timberwolf 250 2WD: 1992-1994
