MK1008536 Wheel Bearing Seal Kit Product Info:

• Seal 1 Diameter Inner (ID) 40mm; Outer (OD) 52mm; Height 6mm
• Seal 2 Diameter Inner (ID) 30mm; Outer (OD) 42mm; Height 7mm
• Seal 3 Diameter Inner (ID) 22mm; Outer (OD) 42mm; Height 5mm
• Bearing 1 Diameter Inner (ID)15mm; Outer (OD) 42mm; Height 13mm; Bearing 2 Diameter Inner (ID)17mm; Outer (OD) 47mm; Height 14mm

Included in This Kit:

(QTY 2) NICHE 519-CBB2232R Single Row, Deep Groove, Ball Bearing

Substitute For OEM Part Numbers(s): 96150-63020-10, 96140-63020-10, 96120-63020-10, 93306-30212-00, 91052-KR3-005, 91052-HB5-671, 91051-KEH-662, 91051-KC2-882, 601B6302UU, 601B6302U, 09262-15027, 08153-63027, 08144-63027, 08123-63027, 08113-63020

(QTY 3) NICHE 519-CBB2236R Single Row, Deep Groove, Ball Bearing

Substitute For OEM Part Numbers(s): J10-81158-10, 96150-63030-10, 96140-63030-10, 96140-63030-00, 96140-63030, 96120-63030-0S, 96120-63030, 93306-30317-00, 92045-3746, 92045-0733, 91054-MT6-832, 91054-MT6-831, 91051-MGZ-J01, 91051-KS4-003, 91051-KPS-732, 91051-KPS-731, 601B6303UU, 38751-590-004, 31582-50F20, 31114-PGK-A01, 31114-P01-014, 31114-P01-004, 26872-G01, 26872G01, 23521-G1, 23521G1, 16877-G1, 16877G1, 1135350, 08143-63037, 08124-63037, 08123-63037

(QTY 1) NICHE 519-CSE2272A Seal Type TC 40x52x6

Substitute For OEM Part Numbers(s): 93106-40027-00, 93102-40367-00

(QTY 1) NICHE 519-CSE2273A Seal Type TC 30x42x7

Substitute For OEM Part Numbers(s): 92049-0130, 64729-04601

(QTY 1) NICHE 519-CSE2286A Seal Type TC 22x42x5

Substitute For OEM Part Numbers(s):

Compatible with the Following Vehicles:

Kawasaki Vulcan 750: 1986-2006
